PMK Rogowski Coil Current Probes: Non-Intrusive Measurement for High Currents

Welcome to Revinetech's elite category for PMK Rogowski Coil Current Probes. In power electronics, motor control, and inverter testing, precise, non-intrusive current measurement is essential, especially when dealing with high currents and fast switching transients. PMK Rogowski coil probes are advanced instruments that provide accurate, isolated measurement of AC current, pulsed current, and high-frequency components without suffering from saturation effects common in traditional current transformers.

You are seeking robust, high-bandwidth current measurement devices that offer complete isolation, excellent linearity, and a flexible, clip-around design for measuring currents in challenging conductors. Our selection features the complete range of PMK Rogowski probes, designed for seamless integration with oscilloscopes and power analyzers. Trust Revinetech to provide the genuine PMK Rogowski Coil that delivers certified precision, superior transient response, and the essential safety and diagnostic accuracy required for optimizing your power systems.

Why PMK Rogowski Coils Excel in Power Electronics

Rogowski coils operate on the principle of induction but differ fundamentally from current transformers (CTs) by having a non-magnetic core. This distinction provides significant advantages for modern power testing.

Freedom from Saturation and High Linearity

The core strength of a PMK Rogowski Coil lies in its air-core (non-magnetic) design, which eliminates major limitations of traditional CTs:

• No Magnetic Saturation: Unlike CTs, the air core ensures the probe does not saturate, even when measuring massive current transients (inrush current or fault currents). This guarantees linear, accurate measurement across the full dynamic range.



• Wide Dynamic Range: Provides excellent linearity across a wide measurement range, making the probes suitable for accurately measuring small ripple currents and large peak currents with a single instrument.



• High-Frequency Response: The design allows for a much wider frequency bandwidth than standard clamp-on probes, essential for accurately capturing the high-frequency harmonics and fast switching edges found in SiC and GaN power converters.

Safety, Isolation, and Ease of Use

PMK Rogowski probes are designed for practical, safe use in high-power environments:

• Complete Galvanic Isolation: The non-contact, clip-around design provides full galvanic isolation between the measured conductor and the output signal. This ensures maximum user safety and protects the connected oscilloscope from high-voltage transients.



• Flexible and Easy to Use: The flexible, tear-drop shape of the coil allows the probe to be easily clipped around large or irregularly shaped conductors (like busbars), simplifying connections in tight industrial spaces.



• Low Insertion Impedance: The probe operates without requiring a primary winding, introducing virtually no impedance into the measured circuit, ensuring non-intrusive current sensing.

Exploring the PMK Rogowski Coil Product Categories

Our catalogue features the specialized lines of PMK Rogowski Coil Current Probes, categorized by their maximum current rating, coil diameter, and integrated features.

High-Bandwidth Diagnostic Probes

These instruments are essential for R&D and advanced debugging applications requiring maximum signal fidelity:

• Fast Transient Response: Optimized for capturing high di/dt events and fast switching currents, crucial for analyzing turn-on/turn-off transients in inverters.



• Wide Measurement Range: Offering models with varying sensitivity to measure currents ranging from a few amperes up to thousands of amperes.

• Integrated Conditioning: The probe system includes a dedicated active integrator circuit (often battery or externally powered) which converts the coil's output (voltage proportional to the derivative of the current) into a stable, direct voltage waveform proportional to the actual current.



Flexible and Large Diameter Coils

Designed for installation versatility in large power systems:

• Large Coil Diameters: Offering coils with large diameters to easily wrap around thick cables, large busbars, or multiple conductors simultaneously.

• Rugged Construction: Built with durable materials and robust connectors suitable for repeated use in demanding field and laboratory environments.

Power Measurement Accessories

PMK offers various accessories to simplify integration with measurement instruments:

• BNC and Safety Connectors: Featuring standard BNC outputs and safety-rated connector housings for reliable connection to oscilloscopes and power analyzers.

• Calibration Support: Tools and documentation to ensure the coil's sensitivity remains accurately calibrated and traceable.

Partner with Revinetech for PMK Rogowski Assurance

Selecting the ideal PMK Rogowski Coil Current Probe requires assessing the maximum peak current, the necessary coil diameter, and the required bandwidth. Revinetech is your authorized source for the complete PMK probe and measurement portfolio. Our technical specialists are ready to assist you in matching the certified precision, high linearity, and non-intrusive design of the right PMK Rogowski Probe to your power electronics debugging and efficiency analysis demands.

Achieve accurate, saturation-free current measurement. Browse our catalogue of PMK Rogowski Coil Current Probes today, and contact us for expert advice and a personalized quote.

Frequently Asked Questions (FAQs)

What is the main benefit of a Rogowski Coil over a standard Current Transformer (CT)?

The main benefit is freedom from saturation. Because the PMK Rogowski Coil uses an air core (non-magnetic), it cannot saturate, ensuring highly linear and accurate measurement of very large current transients and fault currents, which is impossible for magnetic-core CTs.

How does a PMK Rogowski Coil measure current without a magnetic core?

The coil measures the rate of change of current (dI/dt) by generating a voltage proportional to the magnetic field. This voltage signal is then processed and integrated by a dedicated active electronic circuit within the probe to produce a final voltage waveform directly proportional to the actual current (I).

Why are Rogowski coils preferred for testing SiC and GaN inverters?

Rogowski coils are preferred for SiC and GaN testing because these devices switch extremely fast. The Rogowski's wide frequency bandwidth and low parasitic inductance allow it to accurately capture the high di/dt (rate of change of current) and fast switching harmonics generated by these next-generation semiconductors.

Does the PMK Rogowski Probe require a battery or external power?

Yes. The coil itself is passive, but it requires an active electronic integrator circuit to convert the dI/dt signal into a current (I) waveform. This active circuit requires a power source, typically a battery or an external power supply.

What is the significance of the coil's flexible, clip-around design?

The flexible design allows the PMK Rogowski Coil to be easily opened and clipped around large conductors, irregularly shaped busbars, or conductors in tight spaces where a rigid clamp-on probe cannot fit. This simplifies connectivity in complex industrial and power electronics test setups.
